China 1D 2D Qr Bar Codes Android Mobile Phone Computer Handheld Wired Wireless 2.4G Bar Code Passport Handheld Barcode Scanner wholesale

1D 2D Qr Bar Codes Android Mobile Phone Computer Handheld Wired Wireless 2.4G Bar Code Passport Handheld Barcode Scanner

Name: 1D 2D Qr Bar Codes Android Mobile Phone Computer Handheld Wired Wireless 24G Bar Code Passport Handheld Barcode Scanner
Brand: WCMI
Price: 1 USD

Ask Latest Price

Video Channel

private mold :Yes

products status :Stock

type :Barcode Scanner

scan element type :CMOS

colour depth :32 Bit

interface type :usb, COM, PS/2

max paper size :A4

optical resolution :4mil

Brand Name :WCMI

Place of Origin :China

warranty(year) :2-Year

after-sales service :Return and Replacement, Others, Repair, Free spare parts, Onsite Training and Inspection, Call Center and on-line Technical Support

software development kit (sdk) :Yes

color :Black, blue

Product name :SD5130 Handheld Barcode Scanner

Image (Pixels) Sensor :640 X 480 CMOS @ 30fps

Precisions :1d ≥4mil / 2d ≥10mil

Motion Tolerance :50cm/s

Language Supported :English/Customized

Symbol Contrast :≥15%

Weight :175g

Dimensions :63mm x 88mm x 138mm

Interface :USB

Storage temperature :-40℃ ~ 70℃

Contact Now

Add to Cart

View Product Description

1D 2D Qr Bar Codes Android Mobile Phone Computer Handheld Wired Wireless 2.4G Bar Code Passport Handheld Barcode Scanner

Products Description

Product Parameters
_General	Type	Handheld Barcode Scanner
		Product model	SD5130
		Brand Name	WCMI
		Products Status	Stock
		Place of Origin	Tianjin,China
		Private Model	Yes
		Warranty(Year)	15 months
		After-sales Service	Return and Replacement; Free spare parts
		Certification	CE、RoHS、FCC
		Language Supported	English/Customized
Scan code performance	Image (Pixels) Sensor	640 X 480 CMOS @ 30fps
		Light Source	Fill Light: White 6500K LED / Aiming Light: Red LED
		View Angle	Horizontal 32°, Vertical 24°
		Decoding capability	2d: QR 、PDF417、DataMatrix（ECC200）、Aztec、HANXIN code、Maxicode、Micro QR、Micro PDF417 1d: EAN13、EAN8、UPC-A、UPC-E0、UPC-E1、 Code128、Code39、Code93、CodaBar 、Interleaved 2 of 5、Industrial 2 of 5、Matrix 2 of 5、Code11、 MSI Plessey 、RSS-14、RSS-Expand、RSS-Limited、 Standard 2 of 5、Code 16K、Plessey、ChinaPost
		Depth of Field	Code39: 40~105mm （5mil） EAN13: 40~280 mm （13mil） CODE128: 45~370 mm （15mil） QR:20-210mm(15mil)
		Scan Angle	Rotation: 360°, Pitch: ±60°, Deflection: ±60°
		Scan Mode	Continuous mode, Induction mode, Manual mode, Command-Triggered Mode
		Precisions	1d ≥4mil / 2d ≥10mil
		Symbol Contrast	≥15%
Physical Parameters	Weight	<200g
		Dimensions	138.18mm x 101.51mm x 63mm
		Interface	USB
		Prompt Mode	LED prompt，Vibration motor and buzzer
		Voltage	DC+5V ±5%
		Line Length	1.8m
		Current	320mA
Environmental Parameter	Operating temperature	-20℃ ~ 60℃
		Storage temperature	-40℃ ~ 70℃
		Operating Humidity	5%RH~95%RH (Non-condensing)

ABOUT US

Shipping and Service

1.OEM:

(A)Silk print on the goods
(B)Firmware/software Customized
(C)Customized packing

2.ODM:

We can customized products according to the requirements of customers

3.Low MOQ:

We accept MOQ 1 pcs.

4.Team:

36 R&D staff technical team and professional sales

Q1: Why customer choose us?

A: ISO9001 & ISO14001 factory with strictly quality control system.Prompt after-sales service.

Q2: Do you have the items in stock?

A: The most of products are in stock.We can send the goods out within 7 days after payment
received.For the goods are out of stock,production time is about 7-10 days.

Q3: What’s the warranty policy for the barcode scanners?

A: We provide 24 months maintenance warranties. During warranty, free and quick advice for repairing, free spare parts if it is necessary for replacement or new barcode scanners replacement in the next order.

Q4: If the goods are damaged badly,who is responsible for it?

A: We will be responsible for the damaged goods when it is damaged during transport,and we can exchange the
new goods for you.

Q5: Can you make OEM or ODM for products?

A: OEM and ODM products is available for customer,as long as customer meet the MOQ.

Q6: What about MOQ?

A: For production,we can accept sample order firstly,so there is not limit for MOQ

Q7: Besides the English language,do your printers support other languages?what operation system they backup?

A: Yes,our printer not only supports English language,but also Russian,Spanish,Portuguese ect. 48 different languages available,and it backups IOS,Android,Windows,Linux,Opos operation systems.

Q8: why should you buy from us not from other suppliers?

A: We have much experience in the development barcode scanner and all in one scanning products. Our products range incluseds wired and wireless barcode scanner, omni-directional barcode scanner,，barcode scanner engine, algorithm licenses . For the small quantity project, we are availble for the fast feedback and customized.

Q9: What warranty and after-sale service do you offer?

A: Each production will have two year (24 months) warranty. Free components will be offered for repair in warranty period,if the issue caused by non-artificial damages.
